NuGraf rendered image on front cover of "Pro/E the Magazine" by Genexis Design Inc.

Industrial Design Imagery by IDE Inc.

For many years IDE Inc. has been a very active user of Okino's NuGraf Rendering System software. This active use of the software has resulted in many top quality images, some of which have become quite well known in the CAD community such as the red "Okino Camera" and the Concept PDA.

Copyrights: Data and image used by permission and Copyright (c) by IDE Inc..

The newest contribution to the Okino "Customer Picture Gallery" collection is the following "Ziatech Computer Server". The Ziatech server bezels were created using two programs. The Industrial designed exterior surfaces were created using the NURBS surface modeler Rhino and the mechanical design was created with Pro/E. The rendering was created with Okino's NuGraf. The image uses 8 different texture maps and 3 light sources.

Silicon Film, http://www.ideinc.com/silfilm.html

A digital film cartridge that allows some existing, non-digital, SLR cameras to take pure digital images. It is a modular system comprised of 3 components. Created concurrently in both Rhinoceros and Pro-e, then rendered in NuGraf for presentation to the client before display models, color studies and prototypes were developed. The final Rendering was done in NRS with all product graphics being projected onto the polygon meshes using NuGraf.

Colorado Micro Display, http://www.ideinc.com/cmdphs.html

IDE developed a prototype for technology presentation. A Pro-E solid model was exported into Okino NuGraf software where the final rendering was done.

Anritsu Synthesized CW Generator MG3690A, http://www.ideinc.com/anritsu.html

An RF and Microwave signal synthesizer. The exterior surfaces were all modeled in Rhino. These surfaces were rendered in NuGraf. IDE used a combination of Adobe  Illustrator and Rhino to develop the interface and bezel graphics/markings. When the final concept was selected the surfaces were exported from Rhino and then imported into Pro-E for mechanical design. The final Rendering was done in NuGraf with only a few problematic product graphics being applied in Adobe Photoshop, otherwise all graphics were projected onto the polygon meshes using NuGraf.

Creative Labs Nomad Jukebox, http://www.ideinc.com/creative.html

A digital music jukebox holding up to 150 CDs of music. Created concurrently in both Rhinoceros and Pro-e, then rendered in NuGraf for presentation to the client before display models, color studies and prototypes were developed. The final Rendering was done in NuGraf with all product graphics being projected onto the polygon meshes using NuGraf.

Solid Edge Assemblies Rendered With Okino's NuGraf

As part of the promotional roll-out of Okino's native Solid Edge import converter, Unigraphics Solutions (developer of Solid Edge) used NuGraf to import assemblies from Solid Edge and create the following images using the NuGraf multi-threaded ray tracer.

Copyrights: Data and images Copyright (c) by Unigraphics Solutions Inc..

Genexis Design Image on 'Pro/E the Magazine' Front Cover

Okino Computer Graphics is pleased to have one of its earliest adopters of its NuGraf Rendering System, Genexis Design, Inc. of Toronto Canada, have a NuGraf rendered image published on the front cover of "Pro/E the Magazine".

Click here for the main WEB page which hosts this image and its overview on the Okino WEB site.
