AutoCAD Solid Model (ACIS SAT) Rendering

This is the first model that was rendered via use of Okino's ACIS SAT geometry import converter.

The turn-around time from import to final rendering was about 40mins, most of which was consumed in deciding what materials and what colors to assign to the object. The actual ray traced rendering took 2mins to complete on a PentiumPro machine.

Copyrights: The camera model was created by Deam Amir Depay (of IDE Inc.) using AutoCAD's solid modeling capabilities.

"Before NuGraf came along, I was unable to render my Pro-E models easily and so interactively as I do now with NuGraf. Now, with their new SAT translator, I can do the same for my AutoCad solid models as well. I have used many different rendering and translation packages. NuGraf is the easiest, most accurate and reasonably priced package available in my opinion, and their staff is committed to providing technical support, and to improving the product continually."

-Dean Amir Depay, Industrial Product Designer,
IDE Inc. (http://www.ideinc.com)
