PolyTrans|CAD+DCC Translation System - Overview




PolyTrans|CAD+DCC is the leading industry standard for comprehensive visualization and data translation of all 3D CAD/CAM, VR/AR and Digital Content Creation data. With its support of virtually every 2D and 3D file format you will need no other tool to visualize 3D models and translate them to your format of choice. With a user base of the entire 3D industry, and being in use constantly by 3D professionals like yourself, PolyTrans works 'out of the box' in the most complex and demanding of situations - it simply works!

Over the last 3 decades PolyTrans has pioneered and set the standards for crack-free and error-free CAD conversions, 3D scene conversion & size optimization, CAD model reduction & "instance-node" compression, trimmed-NURBS & BREP solids + curve conversion, bi-directional animation transfer, skinned mesh & skeletons conversions, automatic bitmap conversion and many more innovative solutions.

And above all else, Okino is well known for its personal, hands-on and fast technical support plus customer relations. We are one of the most knowledgeable and experienced companies in the 3D realm, for which our focus and interest is to bring proper understanding and awareness to all of our new + existing users.

Important purchasing information: most customers purchase the base-level PolyTrans or NuGraf program and one or more optional add-on modules. Please be careful to review which modules you need before purchasing (add-on modules can be purchased at any time). The PolyTrans-for-Maya sub-product is configured as PolyTrans + DCC/Pack module. The native PolyTrans-for-3ds-Max plug-in system comes with each base-level copy of PolyTrans or NuGraf. Most Okino customers will purchase at least one of: CAD/Pack, DCC/Pack and/or Granite/Pack.

See also these corresponding WEB pages:

PolyTrans stand-alone program
NuGraf stand-alone program (elder brother of PolyTrans)
PolyTrans-for-3ds-Max
PolyTrans-for-Maya
PolyTrans-for-CINEMA-4D
CAD/Pack add-on
DCC/Pack add-on (enables PolyTrans-for-Maya)
Granite/Pack CAD importers add-on (incl. native ProE/Creo, STEP, IGES, Parasolid)
JT importer/exporter add-on
CATIA v4 importer add-on
CATIA v5 importer add-on


 Overview

PolyTrans|CAD+DCC (and its elder brother NuGraf) are stand-alone programs which were written with one purpose in mind: to produce the most mathematically accurate, error free and robust conversions between all major 3D CAD, DCC, VR/AR and VisSim file formats. PolyTrans was the first such program to market and hence has a long standing reputation of providing quality conversions as well as top notch technical support from its development team.

 Common Solutions & Benefits
  • The 'go to' tool for 80-98% reduction of CAD models for VR/AR in Unity, Unreal Engine, Microsoft HoloLens, Oculus Rift and under-powered tablet devices.
  • Converts entire scene files, including meshes with holes, trimmed NURBS, crack-free BREP solids CAD files, hierarchy, animation (format specific), pivot points, vertex normals, U/V tangent vectors, vertex colors, texture coordinates, textures, lights & cameras.
  • Converts & optimizes all major CAD formats to 3ds Max, Maya, CINEMA 4D, LightWave, Blender, OpenFlight and dozens more file formats and 3D programs (full list on WEB site).
  • No CAD model rebuilding necessary. Just import the CAD data as proper "BREP solids" geometry, convert & start your production work.
  • Cross-converts between all major animation packages and 3D file formats with true robustness & quality.
  • Publish to WEB streaming file formats such as DirectX, COLLADA, DWF-3D, HOOPS HSF, SketchUp (Google 3D Warehouse), U3D, XAML-3D & VRML1+2+X3D. Embed U3D in PDF files. Others in development at all times.
  • Highly refined & popular bidirectional 3ds Max <-> Maya pipeline via native plug-ins, with well over three decades of development.
  • The one and only professional 3D conversion program with native CINEMA-4D .c4d support (Okino has been MAXON's primary CAD conversion provider for over 3 decades).
  • Very popular solution for ProE/Creo, SolidWorks, STEP, etc. to DCC conversions -- they just work flawlessly.
  • Acts as a "stepping stone" to allow for massive CAD assemblies to be downsized in PolyTrans first before import into downstream D.C.C applications. This is one of Okino's core specialities, specifically for handling of super-massive oil & gas rigs, drilling platforms & 3D plants.
  • Import and compose 3D scenes from a plethora of 2D/3D file formats then render out to high quality images for print media, WEB presentations, training manuals, or marketing brochures.
  • 30+ year development. Personal and dedicated hands on support direct from the Okino developers.
  • Solid, robust solution used around the world by most major companies and professionals.
  • Easily develop new plug-in modules such as
    import/export, renderers, modelers, etc.
  • Mesh & scene processing toolset including robust polygon reduction system and "parts count optimizer" for top-heavy CAD assemblies.

 Salient Features
  • Very stong & refined support for all major CAD file formats.
  • Optimized since its inception to handle super-massive 3D datasets, such as 500,000 node scenes and hundreds of millions of polygons.
  • An excellent set of robust and well refined tools to deal with the pruning, reduction and node compression of very large source files, including the Okino CAD-centric polygon reduction system.
  • Bidirectional conversions between all D.C.C (animation and digital content creation) programs.
  • Tolerance-based, error-free animation conversion and top notch smooth skinned mesh & skeleton conversion amongst 3ds Max, Maya, CINEMA 4D, LightWave, Collada, FBX, DirectX, U3D, more.
  • Photo-realistic rendering, material editing, texture parameter editing and scene composition (ray tracer in Okino's NuGraf only). Handles very large CAD datasets.
  • ‘Document-centric’ architecture, extensive user interface plug-in API, and 2D/3D import/export API.
  • NVIDIA & AMD real-time shader support, with third generation OpenGL support.
  • “PolyTrans-for-3dsmax” and “PolyTrans-for-Maya”.
  • NuGraf only: Caustics, an amazing
    lens flare system & sunlight calculator.
  • An industry standard for plug-in converter SDK development. Third party developers can create 3D import/export converters, system plug-ins, renderers and many more. Stable and completely refined. Used by dozens of leading 3D software companies.
  • Complete list of features, file formats, brochures, user list and demos available on the Okino WEB site.

 Supported 2D and 3D File Formats

3D Import File Formats: 3ds Max (via PolyTrans-for-3dsMax), Maya (via PolyTrans-for-Maya), Adobe Illustrator, Autodesk Inventor, Biovision BVH and Acclaim motion capture, CATIA v4, CATIA v5, CINEMA-4D, Collada, DirectX, DGN (MicroStation), DXF/DWG, DWF-3D (AutoCAD, Navisworks, Revit and Inventor), Electric Image FACT, ESRI, FBX, HOOPS HSF, IGES (BREP solids & surfaces), JT, LightWave, Okino native BDF, OpenFlight, PARASOLID (BREP solids & surfaces), PDB (protein database), PLY, ProE/Creo (using real PTC ProE/Creo, not reverse engineered software), Rhino-3D/OpenNURBS, SketchUp, SGI-Inventor2 & VRML1, Solid Edge, SolidWorks, STEP (BREP solids & surfaces), STL, U3D (from PDF), USGS DEM & Gtopo-30, VRML2, Wavefront OBJ (Full NURBS + Polygons) and X3D. Contact Okino for support on these or other formats as this list changes over time.

3D Export File Formats: 3ds Max (via PolyTrans-for-3dsMax), Maya (via PolyTrans-for-Maya), CINEMA-4D, Collada, DirectX, DGN (MicroStation), DXF/DWG, DWF-3D, FBX (for Unity. Unreal Engine, MODO), JT, LightWave, NGRAIN 3KO, Okino native BDF, OpenFlight, OpenGL, OSG/IVE, PLY, Rhino-3D/OpenNURBS, SGI-Inventor2, SketchUp, STL, U3D (for 3D-PDF), VRML1+2, XAML, X3D, Wavefront OBJ and others. Contact Okino for support on these or other formats as this list changes over time.

2D Bitmap File Formats: These are used during the automatic bitmap conversion process of the associated 3D import/export converters. TIFF, JPEG, BMP, SGI, GIF, IFF LightWave, IFF Maya, PIC (Softimage), PIX (Maya), PNG, PPM, PSD (photoshop) and Targa. Additional LeadTools supported bitmap file formats: AFP, BMP, CMP, CUT, EPS, EXIF, FLC, GEM, ICO, IFF, ITG, FPX, MAC, MSP, PCD, PCT, CLP, PCX, PSD, PBM, PNG, PTK, SCT, SGI, SMP, RAS, TIFF, TGA, WBMP, XWD and XPM.

 PolyTrans-for-3ds-Max, PolyTrans-for-Maya

These two special, native plug-in versions of PolyTrans run inside 3ds Max and Maya. For well over 3 decades they have provided the industry standard for add-on 3D CAD, DCC and VisSim converters inside of 3ds Max and Maya. This is one of the most popular aspects of PolyTrans in the D.C.C. community. PolyTrans-for-Maya is available via the "DCC/Pack" license. Note: Okino natively supports CINEMA 4D (.c4d), LightWave (lws/lwo) and Softimage (XSI) (dotXSI) file formats so no native plug-in modules are needed for those animation programs.

Popular uses include import of all CAD file formats into 3ds Max and Maya (SolidWorks, ProE/Creo native, STEP, IGES and dozens more), bidirectional conversion of complete scenes between 3ds Max and Maya, cross conversion of OpenFlight VizSim databases, cross conversion of DirectX files with skinning, excellent bidirectional LightWave conversions, and many more long established problem-solving solutions for 3ds Max and Maya users.

 Optional Add-On Modules

Several advanced but optional add-on modules are available (others may also be available):

  • CAD/Pack - Includes Autodesk Inventor importer, DWF-3D importer/exporter (100% perfect, refined and robust for AutoCAD, Navisworks, Revit and Inventor conversions), DWG importer/exporter, Solid Edge import and SolidWorks import.
  • DCC/Pack - Includes PolyTrans-for-Maya native plug-in system and OpenFlight import/export.
  • Granite/Pack - Includes PTC Granite BREP solids-based (crack free) CAD importer licenses: ProE/Creo native parts & assemblies, IGES (solids), Parasolid & STEP. Also includes Okino surface-based IGES importer as a complement to the solids-based PTC IGES importer. Note: this is the main software available on the market which imports native, encrypted PTC ProE/Creo files using a real, licensed copy of ProE/Creo Granite from PTC. Rock solid!
  • CATIA v4 - Import from native CATIA v4 .model files.
  • CATIA v5 - Import from native CATIA v5 .catProduct and .catPart files. Utilizes the actual Dassault CATIA v5 runtime system ensuring 100% fidelity -- it doesn't get any better.
  • JT Open - Import and eport native JT CAD files, using the offical JT Open implementation. Licensed as either the JT importer, or the JT importer+exporter.
